House Plan 277 Sage Meadows, Southern House Plan

PDF: $800.00

Plan Details

  • Plan Number: NDG 277
  • Total Living Space:1601Sq.Ft.
  • Bedrooms: 3
  • Full Baths: 2
  • Half Baths: N/A
  • Garage: Yes 2 Bay
  • Garage Type: Front Load
  • Carport: No
  • Carport Type: N/A
  • Stories: 1
  • Width Ft.: 44
  • Width In.: N/A
  • Depth Ft.: 86
  • Depth In.: 2


Step inside this home and enter a formal foyer with a ten foot ceiling. The foyer opens into a wonderfully spacious family area, perfect for special quality time. Visit with family or entertain friends on the timeless covered porch overlooking a calming lake or rolling golf course. Accessibility to both the great room and a cozy breakfast nook makes this porch both relaxing and convenient. Finally, enjoy your secluded master suite and bath complete with corner whirlpool tub and privacy corner glass block windows.


  • Total Living Space:1601Sq.Ft.
  • Main Floor: 1601 Sq.Ft
  • Upper Floor (Sq.Ft.): N/A
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): N/A
  • Porch (Sq.Ft.): 283 Sq.Ft.
  • Garage (Sq.Ft.): 500 Sq.Ft.
  • Total Square Feet: 2384 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: Yes
  • Main Ceiling Height: 9
  • Upper Ceiling Height: N/A
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 10:12
  • Porch Roof Pitch: N/A
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 23
  • Ridge Height (In.): 3
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
