House Plan 5026 Cedar Mountain, Craftsman Bungalow House Plan

House Plan MEN 5026 Main Floor
House Plan MEN 5026 Main Floor

Floor plans

MEN 5026

House Plan 5026 Cedar Mountain, Craftsman Bungalow House Plan

PDF: $1,550.00

Plan Details

  • Plan Number: MEN 5026
  • Total Living Space:2676Sq.Ft.
  • Bedrooms: 4
  • Full Baths: 3
  • Half Baths: N/A
  • Garage: 2 Bay Yes
  • Garage Type: Side Load
  • Carport: N/A
  • Carport Type: N/A
  • Stories: 1
  • Width Ft.: 87
  • Width In.: 2
  • Depth Ft.: 61
  • Depth In.: 3


This rustic house plan is featured in the Michael E. Nelson collection. The use of a variety of materials on the exterior such as brick, stone, and shake siding give this home exceptional curb appeal. Double entry doors lead into this spacious home. The open concept kitchen and great room feature a large fireplace, high bar, and exposed beams on the ceiling add even more rustic flair to this house plan. The master suite is privately located on the left side of the home and features a spacious bath and walk-in closet. The right side of this house plan is where you will find three additional bedrooms and two additional baths. Completing this plan are a large outdoor living area and a spacious side load garage.


  • Total Living Space:2676Sq.Ft.
  • Main Floor: 2676 Sq.Ft
  • Upper Floor (Sq.Ft.): N/A
  • Lower Floor (Sq.Ft.): N/A
  • Bonus Room (Sq.Ft.): N/A
  • Porch (Sq.Ft.): 553 Sq.Ft.
  • Garage (Sq.Ft.): 724 Sq.Ft.
  • Total Square Feet: 3953 Sq.Ft.
  • Customizable: Yes
  • Wall Construction: 2x4
  • Vaulted Ceiling Height: Yes
  • Main Ceiling Height: 9
  • Upper Ceiling Height: N/A
  • Lower Ceiling Height: N/A
  • Roof Type: Shingle
  • Main Roof Pitch: 12:12
  • Porch Roof Pitch: N/A
  • Roof Framing Description: Stick
  • Designed Roof Load: 45lbs
  • Ridge Height (Ft.): 32
  • Ridge Height (In.): 0
  • Insulation Exterior: R13
  • Insulation Floor Minimum: R19
  • Insulation Ceiling Minimum: R30
  • Lower Bonus Space (Sq.Ft.): N/A
