Floor Plans
Floor Plan #1
Description
This spectacular design is an exceptional creation by Nelson Design Group. Two gorgeous homes adjoined by a common porte cochere make for a wonderful shared area for neighbors – add a basketball goal and you have a courtside seat! Each private residence has a front covered-porch with tapered columns atop rock pillars and a rear-porch privately located behind the garage. These well-planned interiors have a large great room with fireplace and a quaint breakfast nook centered between the dining room and spacious kitchen. The master suite is placed on the main-level and includes a private bathroom with all the amenities and a large walk-in closet with shelves. The upper level has four additional bedrooms and two full bathrooms. One bedroom has a private bathroom and large walk-in closet making the perfect set-up mature family member. A convenient computer/study center is located just at the top of the stairs for easy supervision.
Home Specifications
- Total Living Space: 2516
- Ridge Height (Ft.) 34
- Main Floor (Sq. Ft.): 1360 Sq.Ft
- Ridge Height (In.) 10
- Upper Floor (Sq. Ft.): 1156 Sq.Ft.
- Main Ceiling Height: 9
- Lower Floor (Sq. Ft.): N/A
- Upper Ceiling Height: 8
- Porch (Sq. Ft.): 600 Sq.Ft.
- Lower Ceiling Height: N/A
- Garage (Sq. Ft.): 839 Sq.Ft.
- Garage: 2 Bay Yes
- Bonus (Sq.Ft): N/A
- Garage/Carport Type:Side Load and Porte-Cochere Side Load and Porte-Cochere
- Bedrooms: 5
- Carport: Yes
- Full Baths: 3
- Roof Pitch: 10:12
- Half Baths: 1
- Porch Roof Pitch: N/A
- Stories: 2.0
- Wall Construction: 2x4
- Lower Bonus (Sq. Ft.): N/A
- Vaulted Ceiling: No
- Depth (Ft): 68
- Width (Ft): 116
- Depth (In.) 6
- Width (In.) N/A
- Total Sq. Ft. 3955 Sq.Ft.
- Customizable: Yes
Key Features
- Covered Front Porch
- Covered Rear Porch
- Formal Dining Room
- Great Room
- Grilling Porch
- Home Office/Study
- Main Floor Master
- Nook/Breakfast Area
- Open Floor Plan House Plans
- Peninsula/Eating Bar
- Porte-Cochere
- Split Bedroom Design
- Walk-in Closet
- Wrap-Around Porch
